The World's Most Popular Semi-Hollow Electric Bass

The Jack Casady Signature Bass was designed by Rock and Roll Hall of Fame legend Jack Casady and is the culmination of years of experimentation by the Jefferson Airplane and Hot Tuna bassist to find an instrument with superior electric tone and the response of an acoustic bass. Featuring the Casady-designed JCB low-impedance pickup and a three-position rotary impedance control for a wide range of tonal versatility.

SPECIFICATIONS

BODY

Body Styles : Archtop
Body Shape : LP Signature Bass
Body Material : Layered Maple
Back : Layered Maple
Side : Layered Maple
Binding : Single ply Cream
Body Finish : Gloss

NECK

Scale Length : 863.6 mm / 34 in
Fingerboard Material : Indian Laurel
Fingerboard Radius : 304.8 mm / 12 in
Fret Count : 20
Frets : Medium Jumbo
Nut Material : Imitation Bone
Nut Width : 42.037 mm / 1.655 in
Inlays : Pearloid Trapezoid
Joint : Set

HARDWARE

Finish : Nickel
Bridge : 3-Point Adjustable
Tailpiece : 3-Point Adjustable
Tuning Machines : Die Cast - Clover buttons
Pickguard : Cream with raised E logo
Truss Rod : Dual Action
Truss Rod Cover : Epiphone Bullet with E
Control Knobs : Gold "Speed" knobs
Switch Tip : Black Chicken Head knob
Switch washer : Cream with 50, 250, 500 in Gold hot stamp
Strap Buttons : 2 - bottom and back of heel
Pickup Covers : Cream

ELECTRONIC

Middle Pickup : JCB-1 Low-Impedance Humbucker™
Controls : Master Volume, Master Tone, 3-Position VariTone Tone / Impedance Switch
Pickup Selector : None
Output Jack : 1/4" Heavy-Duty Epiphone

MISCELLANEOUS

Strings Gauge : .50, .75, .85, 105
Case : Optional
Accessories : None
